GX-LY20L Intelligent Building General Training and Assessment Equipment

一、Product Overview

The GX-LY20L Intelligent Building General Training and Assessment Equipment adopts an I-shaped structure, designed specifically for the training requirements of intelligent building systems. According to the needs of the school, the 5A system training units for building automation can be flexibly configured. 1. Floor standing structure: Minimize the floor area and space waste of training equipment, and solve the shortage of workstations in the training room. 2. Four station structure: Each platform can accommodate four training stations at the same time, and each training station can accommodate two training modules at the same time; Each training station has a device installation surface for easy device installation. 3. Independent modules: flexibly exchange various training modules according to the needs of the training content. 4. Bus connection: Realize bus connection between various modules of the same training workstation, the same training platform, or different training platforms, and establish intelligent building systems with different functions, types, or scales. 5. Flexible system configuration: The platform can flexibly configure building automation 5A system training units according to needs.

二、Technical Parameter

1)Boundary dimension: 2440mm × 1730mm × 1798mm (length × wide × High)；

2)Mesh plate size: 748mm × 598mm；

3)Overall power input: AC220V, grounded through the third method；

4)Direct power output: single-phase three core concealed socket, AC220V；

5)Controlled control methods: air switch (with leakage protection), operation and stop buttons；

6)Controlled protection method: 16A single-phase leakage protection switch, DC switching power supply；

7)Controlled power output: Large safety plug-in interface, AC220V, DC24V, DC18V, DC12V, DC5V；

8)DC power supply power: DC24V/6A, DC18V/8A, DC12V/12A, DC5V/5A (shared by four workstations)；

9)Bus connection interface: 2 # secure plug-in interface, 0.25mm2, with a maximum capacity of 8 bits；

10)Computer network interface: RJ45 super Class 5 shielding (10/100Mbps)。

三、Practical training projects

1.Understanding, comparing, wiring, and debugging various commonly used devices;

2.Design, wiring, programming, operation, and exercise of anti-theft alarm systems;

3.Control keyboard programming and operation;;

4.Partition keyboard programming, partitioning, and operation;

5.Manual/automatic perimeter and normal deployment/disarming;

6.Manual/automatic day/night deployment/disarming;

7.Manual/automatic bypass and locking of the defense zone;

8.Exercise of various defense zone functions and output characteristics;

9.The structure, principle, wiring, debugging, application, and integration of various commonly used intercom access control and indoor security equipment into the system;

10.Design, wiring, debugging, and exercise of indoor security system deployment/removal;

11.Design, wiring, debugging, and exercises of resident systems;

12.Design, wiring, commissioning, and exercises of residential and building systems;

13.Design, wiring, debugging, and exercises of residential, building, and community systems;

14.Operation and management of intercom access control and indoor security system management software;

15.Wiring, operation, and management of access control machines;

16.Wiring, operation, and management of attendance machines;

17.Wiring, operation, and management of consumer computers;

18.Operation of one card management software;

19.Operation and management of card issuance;

20.The connection, debugging, and management of the integrated card system.
