GX-JD10H PLC multifunctional training platform

一、 Product Overview

The PLC multifunctional training platform is a practical teaching equipment that integrates two axis positioning model, spindle motion module, PLC, stepper motion control system, servo motion control system, human-machine interface, sensor and other technologies. It is suitable for practical teaching, course design, and graduation design of majors such as mechatronics, electrical engineering, automation, etc.

二、Technical parameters

1) Input voltage: single-phase AC 380V ± 10% 50HZ;

2) Working environment: The ambient temperature range is -5 ℃~+40 ℃, the relative humidity is less than 85% (25 ℃), and the altitude is less than 4000m;

3) Device capacity: ＜ 1.0kVA;

4) Overall size: 1200mm × 800mm × 1100mm。

三、 Practical training projects

1. Wiring of stepper motor and driver control circuit

2. Setting of stepper motor driver

3. Programming of PLC controlled stepper motors

4. Selection of servo motor driver and servo motor

5. Servo motor driver and servo motor wiring

6. Servo motor driver parameter settings

7. Touch screen power supply circuit connection

8. Touch screen configuration interface production

9. Touch screen and PLC communication parameter settings

10. Electrical circuit connection of PLC stepper motor driver and servo motor driver

11. Programming of Two Axis Positioning Control Program for PLC Stepping Motor Driver

12. Programming of Two Axis Positioning Control Program for PLC Servo Motor Driver

13. Frequency converter controls motor forward and reverse rotation

14. Multi stage speed selection, variable frequency speed regulation

15. Frequency converter stepless speed regulation

16. Variable frequency speed regulation based on external analog quantity (voltage/current) control method

17. Instantaneous power outage start control

18. PID variable frequency speed control

19. Accurate positioning, debugging, and operation of the dual axis motion control system

20. Spindle system closed-loop control debugging and operation
